Lamp eigenschappen
Zoom6,7° - 41° motorised linear zoom
Lichtbron
Lichtbron19x15W RGBW Osram Ostar LEDs
CCTCCT control through dedicated DMX channel
Luminous flux(6,7°) 2'339 lm - (41°) 3'811lm @full
Lux(6,7°) 5'575 lx - (41°) 840lx @5 m full
Levensverwachting lichtbron> 50.000 h
Optiek
Lens diameter212mm
Lens typehoneycomb gapless plano-convex optics
Kleuren
KleurmengingRGBW / FC
Wit macro's2.000 K ~ 8.000K
Kleurenwielvirtual colour wheel with macros
Effecten
FX generatoradjustable foreground/background colour, index, speed, direction
Behuizing
Pan angle630°
Tilt angle265°
Kleur behuizingblack, white finishing available
Pan/Tilt resolutiebit 8 / 16bit
Materiaalaluminium structure with hi-resistance polycarbonate cover
Aansturing
ProtocollenDMX512, RDM, W-DMX
DMX kanalen18 / 19 / 20 / 32 / 98channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayLCD high resolution colour display
Firmware upgradeyes, via USB - DMX interface (UPBOX2) not included
W-DMXincluded, wireless solution receiver
RDMRDM ready for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Strobe / shutter1 - 25 Hz, electronic
Bedrijfstemperatuur-10° ~ +45°
LED Controlflicker free operation
Slaapstandpower safe mode when lost DMX
Display accuself-charging battery backup
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik280W
Output (at 230V)6 units on a single power line
Fysieke eigenschappen
Koelingcombination of heat pipe cooling system and low noise fan
Bevestigingany position with quick-lock omega brackets
Signaal aansluitingAmphenol XLR 3p + 5p IN/OUT connectors
StroomaansluitingNeutrik powerCON IN/OUT connectors
IP waarde20
Logistieke eigenschappen
Hoogte verpakking
23.5 cm
Breedte verpakking
33.8 cm
Diepte verpakking
43 cm
Gewicht verpakking
11 kg
