Algemeen
Artikelnummer
21-00614
Merk
ProLights
Artikelnummer fabrikant
ECLEXPOFL150IPVWB
Garantie
2 jaar
Lamp eigenschappen
KleursysteemCC/CW - Tunable White
Vermogen150W
Aansturing
Stand Alone2 rotatory knobs
Lichtbron
Lichtbron150W Variable White LED
CCTCCT control through dedicated DMX channel
Luminous flux@2.700K 7'233 lm; @6.500K 9'777 lm; @full 8'928
Lux@2.700K 81 lx; @6.500K 110 lx; @full 100lx @5 m
Levensverwachting lichtbron> 30.000 hrs (L70B10 @Ta 25° C / 77° F)
CRI94,9 @2.700 K; 93,8 @6.500 K; 93.8 @full
R997,4 @2.700 K; 88,3 @6.500 K; 78,8 @full
TLCI97 @2.700 K; 94 @6.500 K; 98 @full
TM30 Rf> 93,6 @2.700 K; > 88,6 @6.500 K; > 91,5 @full
Kleuren
Kleurmengingtunable white
Wit macro's2.700 K - 6.500K
Kleurenwielbuilt-in white presets
Effecten
Control Resolution16-bit dimmer
Behuizing
Kleur behuizingZwart
Aansturing
ProtocollenDMX512, RDM, CRMX
DMX kanalen1 / 2 / 3 / 5 / 11channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayGraphic User Interface
Firmware upgradevia DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
RDMRDM for remote monitoring and settings
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur-20° C / +45° C (-4° F / +113° F) Ta
Selecteerbare PWM frequentie600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Max. stroomverbruik175W
Output (at 230V)7 units on a single power line
Power factor> 0,99
Fysieke eigenschappen
Koelingactive, silent operation
Bevestigingbracket for hanging and positioning
Signaal aansluitingIP65 Seetronic XLR 5p IN/OUT connectors
StroomaansluitingPowerCon TRUE1
IP waardeIP65
Logistieke eigenschappen
Hoogte verpakking
34.5 cm
Breedte verpakking
35 cm
Diepte verpakking
27.5 cm
Gewicht verpakking
7.1 kg
