Algemeen
Artikelnummer
21-00491
Merk
ProLights
Artikelnummer fabrikant
ECLEXPOFL150FCBK
Garantie
2 jaar
Aansturing
Stand Alone2 rotatory knobs
Lichtbron
Lichtbron150W RGB + Warm White LED
CCT CCT control, + / - green correction, tungsten emulation
Luminous flux5'342lm @full
Lux65lx @5 m full
Levensverwachting lichtbron > 20.000 h
CRIpreliminary 92,8 @5'600K
R9preliminary 94,7 @5'600K
TLCIpreliminary 92 @5'600K
TM30 Rfpreliminary 91,3 @5'600K
TM30 Rgpreliminary 106 @5'600K
Optiek
Extra optieken5° smooth filter on-board
Kleuren
Kleurmenging RGB + Warm White
Wit macro's2.800 K - 10.000K
Kleurenwiel built-in white presets
Effecten
Control Resolution 16-bit dimmer
Body
Kleur behuizing RAL 9004
Behuizingsturdy die-cast magnesium body
Aansturing
Protocolen DMX512, RDM, CRMX
DMX kanalen1/2/5/9/10/12/18channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
Selecteerbare PWM frequentie 600 ~ 40.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik154W
Output (at 230V)7 units on a single power line
Power factor> 0,94
Fysieke eigenschappen
Koeling active, silent operation
Bevestiging bracket for hanging and positioning
Signaal aansluiting Amphenol XLR 5p IN/OUT connectors
Stroomaansluiting Seetronic powerCON TRUE IP65 IN/OUT
IP waarde20
