Algemeen
Artikelnummer
21-00579
Merk
ProLights
Artikelnummer fabrikant
SMARTBATPLUSNEOBK
Garantie
2 jaar
Lichtbron
Lichtbron7x10W RGB + Warm White LED
Luminous flux2'927 lm @Full
Lux1'493lx @5 m full
Levensverwachting lichtbron > 50.000 h
CRIUp to 90
R9Up to 80
TLCIUp to 80
TM30 Rf> 90
Optiek
Extra optieken see available accessories
Kleuren
Kleurmenging RGB + Warm White
Wit macro's2.700 K -10.000K
Kleurenwiel virtual colour wheel with macros
Effecten
Macros built-in white presets
Control Resolution 16-bit dimmer, colours
Behuizing
Kleur behuizing black, mirror finishing available
Materiaal sturdy die-cast aluminium body
Aansturing
Protocollen CRMX+W-DMX, DMX512, RDM
DMX kanalen4/6/10/3 ch in legacy mode | 1/5/11/17channel
Master/Slave for multi-unit sync, set one unit as wireless TX (master DMX) and all others as slave receivers.
Display Graphic User Interface
Firmware upgrade via DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 25 Hz, electronic
Bedrijfstemperatuur 0° ~ +45° Ta
LED Control flicker free operation
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz (SBPLUSNEOPOWER charger not included)
Max. stroomverbruik66W
Batterij16,8V lithium
Fysieke eigenschappen
Koeling passive cooling and fan-free
Bevestiging M12 threaded insert for easy clamp installation
Oplaad connectie magnetic fast-charge in case
IP waarde65 for temporary outdoor application, not for fixed installations
