Lichtbron
Lichtbron4x8W RGBW LEDs
Lux980lx @3 m full
Levensverwachting lichtbron> 50.000 h
Optiek
Lens diameter42mm
Extra optieken25° and 45° optional
Kleuren
Manual colour modemanual adjustment of colour
KleurmengingRGBW / FC
Wit macro's3200 K ~ 10.000K
Kleurenwielvirtual colour wheel with macros
Behuizing
Tilt angle° adjustable foot support for tilt regulation (up to 20°)
Kleur behuizingblack
Materiaalsturdy die-cast aluminium body
Aansturing
ProtocollenDMX512
DMX kanalen4 / 6 / 10channel
Master/Slavefor synchronised operation of more units linked in a chain
DisplayLED display user interface
Firmware upgradeyes, via USB - DMX interface (UPBOX1) not included
W-DMXintegrated, proprietary protocol compatible with WIFIBOX, WDBOX
Electronics
Dimmerlinear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 25 Hz, electronic
Bedrijfstemperatuur0° ~ +35°
LED Controlflicker free operation
Elektrische eigenschappen
Netvoeding100-240V - 50/60Hz
Batterij11,1V lithium
Fysieke eigenschappen
Koelingpassive cooling and fan-free
BevestigingM12 threaded insert for easy clamp installation
StroomaansluitingIEC 10 A IN
IP waarde54
Oplaad connectiepower cable
Logistieke eigenschappen
Gewicht verpakking
4.13 kg
