Algemeen
Artikelnummer
21-00468
Merk
ProLights
Artikelnummer fabrikant
ECLEXPOFL300FCBK
Garantie
2 jaar
Lamp eigenschappen
KleursysteemRGBWW - Full Color
Vermogen300W
Aansturing
Stand Alone2 rotatory knobs
Lichtbron
Lichtbron300W RGB + Warm White LED
CCT CCT control, + / - green correction, tungsten emulation
Luminous flux10'197lm @3.200 K
Lux119lx @5 m
Levensverwachting lichtbron > 20.000 h
CRI93,6 @5'600K
R995,2 @5'600K
TLCI93 @5'600K
TM30 Rf91,7 @5'600K
TM30 Rg105,3 @5'600K
Optiek
Extra optieken5° smooth filter on-board
Min. Zoombereik60
Kleuren
Kleurmenging RGB + Warm White
Wit macro's2.800 K - 10.000K
Kleurenwiel built-in white presets
Effecten
Control Resolution 16-bit dimmer
Behuizing
Kleur behuizingZwart
Materiaalsturdy die-cast magnesium body
Aansturing
Protocollen DMX512, RDM, CRMX
DMX kanalen1/2/5/9/10/12/18channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOXPRO/UPBOX1) not included
RDM RDM for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
Selecteerbare PWM frequentie 600 ~ 40.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik300W
Output (at 230V)7 units on a single power line
Power factor> 0,97
Fysieke eigenschappen
Koeling active, silent operation
Bevestiging bracket for hanging and positioning
Signaal aansluiting Amphenol XLR 5p IN/OUT connectors
StroomaansluitingPowerCON TRUE1
IP waardeIP20
