Lichtbron
Lichtbron230W high-power white LED
CCT(TU) 3.200 K - (DY) 5.700K
Luminous flux(DY) 5°: TBD - 10°: TBD - 14°: 9'649 lm -19°: 9'822 lm - 26°: 10'974 lm - 36°: 10'781 lm - 50°: 9'053 lm @full
Lux(DY) 5°: TBD - 10°: TBD - 14°: 12'000 lx - 19°: 7'118 lx - 26°: 5'571 lx - 36°: 3'105 lx - 50°: 1'569lx @5 m full
Levensverwachting lichtbron > 50.000 h
CRI(TU) >97; (DY) >96
R9(TU) >87; (DY) >96
TLCI(TU) >97; (DY) >96
TM30 Rf(TU) >92; (DY) >89
TM30 Rg(TU) 100; (DY) 100
Optiek
Lens type high-quality glass lens optics
Focus manual
Kleuren
Manual colour mode manual adjustment of colour
Kleurmengingstatic white
Effecten
Gobo maatB, outer: 86 mm - image: 64,5 mm - thickness: 1,1 mm
Behuizing
Kleur behuizing black
Materiaal sturdy die-cast aluminium body
Aansturing
Protocollen DMX512, RDM
DMX kanalen1 / 2 / 5 channel
Master/Slave for synchronised operation of more units linked in a chain
Display Graphic User Interface
Firmware upgrade yes, via USB - DMX interface (UPBOX1) not included
RDM RDM ready for remote monitoring and settings
Electronics
Dimmer linear 0 ~ 100% electronic dimmer
Dimmer curves4 selectable dimming modes available
Strobe / shutter1 - 30 Hz, electronic
Bedrijfstemperatuur -10° ~ +45°
LED Control flicker free operation
Selecteerbare PWM frequentie 600 ~ 25.000 Hz
Elektrische eigenschappen
Netvoeding 100-240V - 50/60Hz
Max. stroomverbruik230W
Output (at 230V)15 units on a single power line
Power factorTU: >0.90 - DY: >0,94
Fysieke eigenschappen
Koeling combination of heat pipe cooling system and low noise fan
Bevestiging bracket for hanging and positioning
Signaal aansluiting Amphenol XLR 5p IN/OUT connectors
Stroomaansluiting Neutrik powerCON IN/OUT connectors
IP waarde20
Logistieke eigenschappen
Hoogte verpakking
34.2 cm
Breedte verpakking
52.8 cm
Diepte verpakking
52.6 cm
Gewicht verpakking
7.11 kg
